Agri-100 Pelletiser
Pelletisers
This machine is the second model in the 280mm range. Due to the chassis configuration of this machine, pellets of 2.2mm to 10mm can be manufactured using different die-ring setups. The Agri 100 pellet machine comes standard with a control panel that is separate to the chassis to IP66 specifications. Apart from starting the pellet mill, this control panel also controls the feed rate of the machine. This control system uses a signal from the main motor to adjust the feeding auger speed. This same system is used on all our pellet mills up to the Agri 250. It can also be retro-fitted to any make or model of pellet mill. The Agri 100 is intended for the medium scale farmer. It must be incorporated into a basic pelleting plant.
Pelletizing machinesSpecifications
- General Type
- Processing Equipment
- Additional Information
- Options:\nFully automated process control PLC systems\nAutomated lubrication system\nWide configuration\nMixer and bagging unit
- Specifications
- Main Drive Motor: 30 Kw\nFeed Motor: 0.75 Kw\nPower Requirement: 56.2 Amp; 3 Phase 380per400 VAC at50HZ\nPower Connection: 56.2\nAmp from supply cable\nNoise levels:\noAt operations panel:\noNo load: 100dB\noFull load: 91dB\noAt 1 meter: 83dB\nRollers: 2 x slide adjusting\nRoller Size: 115 x 80 mm\nCapacity: 1 ton per hour depending on product being pelletised\nDie Ring: Supplied with standard 6 x 40mm alloy die-ring\nMachine Weight: 1189 kg\nAutomatic Lubricator: 3 month applicator\nEquipment required: Loading auger
