Specifications

General Type

Electronic Hardware

Additional Information

Dimensions (Wxdxh): 440x550x130mm. Weight: 49kg. Installation: Rack mounted or wall mounted.

Specifications

Performance - Nominal Voltage: 51.2Vdc. Nominal Capacity: 100Ah. Battery Energy: 5.12kWh. Charge Voltage: 55.68~56.16 Vdc. Discharge Voltage: 45.6~56.16 Vdc. Nominal Charge / Discharge Current: 50A. Nominal Charge / Discharge Power: 2500W. Max Charge / Discharge Current: 100A. Max Charge / Discharge Power: 5000W. Short Circuit current: 350A.
